UPF Detailed Course (Written Course)

The course is prepared by Industry Experts. The course starts at the basic level and then covers advanced topics in detail as well. Suitable for both newcomers and experienced professionals.

The course covers following each of the UPF command with a detailed explanation of all the options

Covers all version UPF1.0, UPF2.X and UPF3.X commands. The details are mentioned below

  • Navigation Commands – set_scope, set_design_top
  • Supply Nets – create_supply_port, create_supply_net, connect_supply_net, create_power_switch
  • Power Domains – create_power_domain, set_domain_supply_net, create_composite_domain
  • Power States – add_port_state, create_pst,add_pst_state, add_power_state, descibe_state_transition
  • Simstates – add_power_state, set_simstate_behavior
  • Attributes – set_port_attributes, set_design_attributes, HDL and Liberty Attributes
  • Supply Sets – create_supply_set, supply set handled, associate_supply_set, connect_supply_set, set_equivalent
  • Strategies – set_repeater, set_retention_elements, set_retention, set_retenntion_control, set_isolation, set_isolation_control, set_level_shifter
  • Implementattion – map_retention_cell, map_isolation_cell, map_level_shifter_cell, map_power_switch_cell, use_interface_cell
  • Control Logic – create_logic_port, create_logic_net, connect_logic_net
  • HDL Interface – bind_checker, create_hdl2upf_vct, create_upf2hdl_vct
  • Code Management – upf_version, load_upf, save_upf, load_upf_protected, load_simstate_behavior, find_objects, begin_power_model, end_power_model,apply_power_model
  • Power Management Cells – define_always_on_cell, define_diode_clamp, define_isolation_cell, define_level_shifter_cell, define_power_switch_cell, define_retention_cell
